Siemens 6AG1131-6BH01-7BA0 – High-Performance Digital Input Module for Harsh Industrial Environments

The Siemens 6AG1131-6BH01-7BA0 is a 16-channel digital input module (DI 16x 24 V DC) from the SIPLUS ET 200SP family, designed for reliable operation in extreme and harsh environments. With conformal coating protection and a wide operating temperature range from –40 °C to +70 °C, this module ensures superior performance even in environments exposed to humidity, dust, or chemicals.


🔧 Key Features

  • 16 digital input channels (24 V DC, type 3 according to IEC 61131)

  • Wide voltage range: 19.2 – 28.8 V DC with reverse polarity protection

  • Configurable input delay: 0.05 ms – 20 ms for flexible application tuning

  • Integrated diagnostics: wire break detection, voltage monitoring, and LED status indicators

  • Compact design: only 15 mm wide, 73 mm high, and 58 mm deep; weight approx. 28 g

  • Extreme environment protection:

    • Operating temperature: –40 °C to +70 °C

    • Conformal coated against moisture, dust, and chemicals

    • Test insulation voltage: 707 V DC

  • Mechanical coding and automatic addressing for easy configuration

  • Fully compatible with TIA Portal / STEP 7 engineering tools


✅ Benefits

  • Rugged and reliable – ideal for use in outdoor, chemical, or dusty industrial areas

  • Advanced diagnostics reduce downtime and simplify maintenance

  • Flexible response time configuration ensures stable operation in dynamic systems

  • Seamless integration with ET 200SP distributed I/O systems

  • Compact footprint saves valuable control cabinet space
