Allen-Bradley Micro800 2080-IQ4OB4

Introduction: The Allen-Bradley 2080-IQ4OB4 Digital Combo Plug-In Module is a highly versatile and cost-effective hardware expansion solution engineered and manufactured 100% in Mexico under the strict quality control benchmarks of Rockwell Automation. Designed specifically as a front-loading accessory for the compact Micro800 programmable logic controller family (compatible with Micro820, Micro830, Micro850, and Micro870 platforms), this module enables automation teams to quickly scale out their binary discrete (ON/OFF) signaling capabilities.

The core engineering advantage of the 2080-IQ4OB4 variant is its space-saving "Combo I/O" architecture. Instead of consuming two separate slot allocations (one for an input card and one for an output card), this high-density module packs 4 digital inputs (4DI) supporting adaptable Sink/Source wiring configurations along with 4 digital outputs (4DO) driven by rugged Sourcing Transistor electronics into a single hardware block. This smart consolidation allows field engineers to preserve open plug-in slots on the controller body for specialized communication adapters or analog nodes. Its slide-in form factor mounts completely flush onto the front face of the host CPU, maintaining the original small geometric footprint of the PLC without cluttering internal panel space.

Key Features & Technical Specifications:

Manufacturer: Allen-Bradley / Rockwell Automation
Product Series: Micro800 Controller Hardware Plug-In Accessories Family
Model Code: 2080-IQ4OB4
Device Type: Digital Input / Output Combination (Combo) System Plug-In Module
Inputs Capacity Layout: 4 discrete input channels, rated at 24V DC with flexible Sink or Source wiring typology.
Outputs Capacity Layout: 4 discrete output channels, rated at 24V DC, solid-state Sourcing Transistor configuration (OB4).
Mechanical Integration: Space-saving slide-in form factor that inserts directly into front-facing slot matrices on standard Micro800 controller bodies, anchored securely via integrated mounting screws.
Termination Interface: Removable high-durability spring clamp terminal block designed for fast, vibration-resistant field wire landing.
Country of Origin: 100% Made in Mexico.
