Leuze PRK25CL1/XX-M12 (50139665)

Introduction: The Leuze PRK25CL1/XX-M12 Retro-reflective Photoelectric Sensor (Order Code: 50139665) is a state-of-the-art cubic-shaped position tracking solution engineered and manufactured 100% in Germany by Leuze electronic. Utilizing a highly focused red laser beam operating under safe Protection Class 1 parameters, this sensor yields uncompromising sensitivity when detecting miniature parts or objects with heavily profiled and reflective surfaces. A core advantage of this specific model is the integrated alignment aid feature, allowing field automation technicians to quickly align and optimize the light path with the target reflector hub, substantially shortening deployment and commissioning cycles.

The sensor features a high-grade hybrid housing scheme constructed from rugged plastic and metal composites, providing exceptional structural impact dissipation. Engineered to excel across volatile factory conditions, it holds premium IP67 and IP69K washdown protection metrics, remaining entirely immune to extreme high-pressure sanitizing jets and severe thermal cycling from -40 °C up to 60 °C. This makes the PRK25C series an absolute standard for cold storage facilities, fish processing automation, and sterile food production environments.

Key Features & Technical Specifications:

Manufacturer: Leuze electronic (Germany)
Product Series: 25C Series (Cubic Photoelectric Sensors)
Model Code: PRK25CL1/XX-M12
Part Number (PN): 50139665
Device Type: Polarized Retro-reflective Photoelectric Sensor
Special Hardware Utility: Integrated optical alignment aid.
Emitter Light Source: Visible Red Laser, Laser Protection Class 1 rated.
Operational Voltage Margin: 10 ... 30 V, DC.
I/O Configuration Matrix: Equipped with 1 digital switching input and 1 digital switching output.
Housing Architecture: Compact industrial Cubic layout.
Material Composition: Heavy-duty Plastic and Metal structural blend.
Electrical Connectivity: Standard industrial M12 connector, 4-pin deployment layout with high-durability PUR insulation.
Ambient Thermal Tolerance: -40 ... 60 °C operational threshold (ideal for blast freezers or hot processing plants).
Ingress Protection Rating: IP 67 and IP 69K certified.
Country of Origin: 100% Made in Germany.
