Wuhan Xingda Vietnam,The Sodium Hypochlorite Generator LHB-101 Wuhan Xingda

LHB Sodium Hypochlorite Generator with Electrolytic Seawater

The sodium hypochlorite Generator with Electrolytic Seawater functions to produce highly active sodium hypochlorite solution by high-speed electrolysis of natural seawater. Following dehydrogenization and storage, the sodium hypochlorite is fed to dosing point as biocide to effectively kill microbes, oceanic creatures, algae and pathogens containing in the water body, so as to prevent the circulating water pipeline and condenser system from blockage.

Widely used inthe coastal power station circulating cooling water, chemical, petrochemical and offshore drilling platforms, desalination, ship ballast water treatment and other fields.

Principle of Work

The NaCl in Seawater or brine is used as electrolyte in the electrolytic chlorine system, through the DC current electrolysis to produce a certain concentration of sodium hypochlorite.

The basic reaction that takes place in an electrolytic cell

Anodic chlorine gas precipitation

2Cl-=Cl2+2e--------①

2Cl--2e→Cl2

Cathode hydrogen precipitation

2H++2e=H2 --------②

In which Cl2 deposited on the anode is dissolved in the electrolyte to form HCl and HClO, the H2 precipitated on the cathode generates OH-. Because there is no septum between the cathode and anode, that is to complete the homogeneous secondary chemical reaction. The total reaction is:

NaCl+H2O→NaClO+H2



100% China
 Origin

Wuhan Xingda
 Vietnam

Model: LHB-101
 Voltage: 160-180VDC
 Productivity rate: 101 kg/h
 Current: 2480A (DC)
 Seawater flow rate: 67-101m3/h
 Size: 4738*2200*3200 mm
 The Sodium Hypochlorite Generator
