The Wolf Safety LinkEx™ LED Floodlite LL-260 & LL-260/SS series represents a premium range of high-output, wide-beam portable floodlights manufactured by Wolf Safety (United Kingdom). Specifically engineered to deliver bright, ambient illumination during temporary maintenance, inspection, and construction operations in volatile industrial environments, this series holds full ATEX and IECEx certifications for both Gas (Zone 1, Zone 2) and Dust (Zone 21, Zone 22) hazardous locations.

This product line offers two distinct structural frame configurations:
- LL-260: Standard model featuring a lightweight, powder-coated aluminum bridle stand for easy maneuverability.
- LL-260/SS: Heavy-duty variant constructed with a full 316L Stainless Steel frame and stand, engineered specifically to withstand highly corrosive offshore environments, marine salt spray, and aggressive chemical plants.

Equipped with an advanced high-efficiency LED array, the LinkEx™ LED Floodlite delivers an impressive light output of over 5,800 Lumens while consuming minimal electrical power. An integrated anti-glare shield diffuses the light beam evenly, eliminating harsh glares and shadow spots for operators working at close quarters. A key operational feature is its linkable (daisy-chaining) capability: fitted with ATEX-certified socket and plug assemblies, multiple floodlights can be connected in series on a single power line to illuminate extensive work zones.

Constructed from marine-grade aluminum alloy, an IK10 impact-resistant Polycarbonate lens, and sealed to IP66/IP67 ingress protection, the floodlight withstands extreme mechanical shocks and harsh weather. Featuring 360-degree tilt adjustment and versatile mounting options (magnet fixings, scaffold clamps, tripod stands), the Wolf Safety LL-260 & LL-260/SS series is the preferred choice for offshore platforms, oil tankers, petrochemical plants, and underground civil works.

• Manufacturer: Wolf Safety Lamp Company Ltd
• Product Line: LinkEx™ LED Floodlite (Portable ATEX Floodlight)
• Grouped Model Numbers:
  - LL-260: Powder-coated aluminum frame version
  - LL-260/SS: 316L Stainless Steel frame version
• Explosion-Proof Certifications: ATEX & IECEx (Certified for Zone 1, 2, 21, 22)
• ATEX Marking: II 2 GD Ex eb mb op is IIC T4 Gb | Ex tb op is IIIC T118°C Db
• Temperature Class: T4 (Max surface temperature 135°C)
• Voltage Configurations:
  - High Voltage (HV) Version: 100V - 254V AC/DC (50/60Hz)
  - Low Voltage (LV) Version: 18V - 50V AC/DC (50/60Hz)
• Light Source: High-output LED array (>100,000 hours life expectancy)
• Luminous Flux Output: ~5,800 Lumens (Cool White 6,000K)
• Ingress Protection Rating: IP66 / IP67 (Dust-tight and heavy seas/immersion resistant)
• Impact Resistance: IK10 (Heavy-duty Polycarbonate lens)
• Daisy-Chaining Feature: Integrated ATEX plug & socket arrangement for continuous linking
• Operating Ambient Temperature: -20°C to +50°C
• Housing Material: Marine-grade aluminum alloy with epoxy powder coating
• Frame / Stand Material:
  - LL-260: Powder-coated aluminum
  - LL-260/SS: 316L Stainless Steel
• Net Weight: ~8.2 kg (LL-260) / ~10.5 kg (LL-260/SS)
• Overall Dimensions (H x W x D): 430 mm x 420 mm x 280 mm
