Infrared Sensing Head RAYMI310LTSCB3 Fluke Vietnam





Compact and rugged, this sensor provides continuous non-contact temperature monitoring up to 1112°F (600°C) for OEM applications and manufacturing processes. In addition, this sensing head comes in an IP65 stainless steel enclosure to ensure long-term performance and features a 10' (3 m) cable.

Raytek RAYMI310LTSCB3 Offers

Features

  • Read temperature ranges from -40 to 1112°F (-40 to 600°C)
  • Withstand ambient temperatures up to 248°F (120°C) without cooling
  • Response time of 130 ms
  • Optical resolution of 22:1
  • Dedicated close focus lens (sold separately) for spot sizes down to 0.02" (0.5 mm)
  • Industrial rugged cable: Silicone and halogen free, resistant against oil, bases, and acids
  • No cable bending/moving effects, allowing continuous reliable measurement in moving installations (robotic arms, linear drives, chains, etc.)

Applications

  • OEM
  • Manufacturing
