The Agr International Thickness 360™ Gauge (Thickness 360® measurement system) is 100% designed, engineered, and manufactured in the United States by Agr International, Inc. – the internationally recognized global benchmark in container inspection, dimensional gauging, and quality testing systems. Purpose-built to provide the most complete, automated material distribution evaluation for glass and rigid packaging, the Thickness 360™ supersedes traditional tactile measurement tools with an ultra-precise, non-destructive optical methodology that protects product surfaces from scratches or damage.

The key proprietary innovation of the Thickness 360™ is its patented vision-guided, three-axis robotic positioning system paired with a high-resolution optical measurement head. Unlike conventional gauges that struggle with asymmetrical geometry, the Thickness 360™ dynamically tracks the product contour to ensure the optical beam is always positioned strictly "normal to surface" (perpendicular) at every measuring coordinate. Consequently, the system delivers laboratory-grade measurement integrity across challenging features including oval profiles, rectangular corners, tilted sidewalls, shoulder tapers, and recessed label panels with precision reaching ±0.02 mm.

The Thickness 360™ is engineered as a core thickness measurement engine seamlessly integrated into Agr's premier automated sampling stations—including the Dimensional Sampling Gauge Series (DSG400, flagship DSG500, and the DSG-P for pharmaceutical vials and small containers) as well as the OmniLab multi-testing platform. This seamless configuration empowers manufacturers to capture 360-degree complete sidewall thickness data simultaneously alongside dimensional parameters (height, diameters, lean, finish angles, pushup) in a single hands-free sequence. Coupled with automated mold correlation and full Industry 4.0 data reporting, the Thickness 360™ is an indispensable asset for container lightweighting initiatives, hot-end/cold-end optimization, and premium glass packaging production lines worldwide.

• Manufacturer: Agr International, Inc.
• Origin: 100% USA (United States)
• Product Series: Automated Non-Contact Optical Thickness Measurement System
• Model: Thickness 360™ Gauge (Thickness 360®)
• Measurement Technology: High-resolution non-contact optical measurement with patented vision-guided 3-axis robotic positioning
• Positioning Orientation: Automated dynamic "Normal-to-Surface" perpendicular alignment across all scanning angles
• Inspection Coverage: Full 360-degree rotational profile mapping across body sidewall, shoulder, tilted panels, corners, neck, and base
• Container Geometry Compatibility: Round and non-round containers (flasks, oval, square, polygonal, shaped containers)
• Measurement Accuracy: Up to ±0.02 mm (±0.0008 in.)
• Measurement Repeatability: High-precision repeatability eliminating operator dependency
• System Integration Capabilities:
  - Standard built-in station on the flagship Agr DSG500 Dimensional Sampling Gauge
  - Integrated option on Agr DSG400 and DSG-P (pharmaceutical containers and vials)
  - Integrated station inside Agr OmniLab automated multi-station testing systems
• Automated Setup Feature: Compatible with Agr’s exclusive patented AutoJob® one-touch job setup routine
• Data Analytics & Quality Control: Complete mold correlation, 3D thickness distribution mapping, and single consolidated quality reporting
• Plant Connectivity: Industry 4.0 ready digital communications for plant-wide process control systems (MES/SCADA)
• Applicable Industries: Commercial glass container and bottle manufacturing (beer, wine, spirits, food, cosmetics), pharmaceutical glass manufacturing (vials, ampoules, infusion bottles, dental cartridges), glass lightweighting sustainability programs, container design R&D centers, and third-party certified packaging laboratories.
