Bühler TC-Midi Series Temperature Sensor (TC-Midi, TC-Midi+, TC-Midi-2, TC-Midi-3)
Price: Contact
Brand: Buhler
Category: Thiết bị đo lường & Kiểm tra
Supplier: AnhNghiSon
Origin: Germany
0911472255The Bühler TC-Midi Series Temperature Sensor lineup is a versatile and reliable mid-range fluid temperature monitoring solution engineered by Bühler Technologies (Germany). Designed to bridge the gap between miniature sensors and large industrial measuring systems, this series offers an optimal balance of compact physical footprint, mechanical robustness, and multi-functional integration capabilities.
The Bühler TC-Midi Series encompasses 4 primary model variants tailored to meet specific system engineering demands:
1. Bühler TC-Midi: The standard model featuring a primary thermal switch or basic sensing element, ideal for single-point temperature monitoring and alarm applications.
2. Bühler TC-Midi+: An enhanced version equipped with continuous analog output signals (such as 4-20mA or Pt100) alongside flexible electrical connectors for real-time PLC integration.
3. Bühler TC-Midi-2: Incorporates dual switching contacts (Dual Thermal Switch), allowing operators to set two distinct temperature thresholds (e.g., High Temperature Warning and Emergency System Shutdown).
4. Bühler TC-Midi-3: Advanced multi-stage variant featuring up to 3 independent switching points or a hybrid configuration combining thermal switches with continuous transmitters for complex thermal management.
All models in the TC-Midi Series feature heavy-duty metallic housings with superior corrosion resistance, engineered to withstand high operating pressures in hydraulic oil, lubricating fluids, and coolant applications.
• Manufacturer: Bühler Technologies
• Product Line: TC-Midi Series Industrial Temperature Sensors
• Included Models: TC-Midi / TC-Midi+ / TC-Midi-2 / TC-Midi-3
• Country of Origin: Germany
• Operating Temperature Range: -20°C to +120°C (customizable)
• Wetted Materials: Stainless Steel / Corrosion-resistant alloy
• Maximum Operating Pressure: Up to 100 bar
• Switching Point Configurations:
- TC-Midi / TC-Midi+: 1 switching point / Continuous output
- TC-Midi-2: 2 independent switching points (Dual Switch)
- TC-Midi-3: 3 independent switching points (Triple Switch)
• Process Connection Threads: G1/2, G3/4 or standard industrial threads
• Output Signals: Switching contact (NO/NC), Pt100, Pt1000, 4-20mA analog
• Electrical Connectors: M12 (4-pin / 8-pin), Hirschmann connector
• Ingress Protection Rating: IP65 / IP67
• Applicable Media: Hydraulic oil, lubricating fluids, cooling water, industrial liquids
