The Mayr ROBA®-linearstop Pneumatic Linear Safety Brake Size 60 Type 381.110.0 is a high-performance linear axis clamping and holding device manufactured by Mayr (Germany). Engineered specifically to prevent unintentional gravity drops of vertically moving loads (such as CNC vertical Z-axes) during power failures, system shutoffs, or emergency stops, it delivers uncompromised operational safety.

Operating on the fail-safe spring-applied principle, internal pre-loaded springs exert mechanical force to clamp the linear rod with a heavy-duty holding force of 7,300 N when pneumatic pressure is removed. Proper release of the clamping mechanism requires a minimum pneumatic operating pressure of 4.5 bar. Featuring an aligned direction threaded joint configuration, compact housing, backlash-free force transmission, and high static/dynamic holding capacity, the ROBA-linearstop Size 60 ensures maximum personnel and equipment protection.

• Manufacturer: Mayr (Germany)
• Product Series: ROBA®-linearstop Pneumatic Series
• Product Category: Pneumatically released spring-applied linear safety brake
• Size: Size 60
• Configuration Type: Type 381.110.0
• Holding Force Setting: 7,300 N
• Minimum Operating Release Pressure: 4.5 bar required for proper release
• Maximum Operating Pressure: 6.0 bar - 8.0 bar
• Threaded Joint Interface: Aligned direction
• Operating Principle: Spring-applied mechanical clamping, pneumatic pressure release (Fail-safe)
• Functional Scope: Static holding brake and dynamic emergency stop clamping
• Key Features: Completely backlash-free clamping, ultra-fast response time, robust holding power
• Application Scope: Vertical Z-axes, CNC machinery, pneumatic/hydraulic rods, factory automation
• Standards & Approvals: ISO 9001, CE, RoHS compliant
