Wireless control R05001 RF-I/O 32 Comfile Technology Vietnam
Price: Contact
Brand: COMFILE Technology
Category: 4.0 Industry
Supplier: ansvietnam
Origin: USA
Gọi lại cho tôi
0911472255Wireless control R05001 RF-I/O 32 Comfile Technology Vietnam
- • Input and output status can be transmitted as if connected by an invisible wire. When an input is received on one side, the corresponding output on the other side turns ON.
- • It can be used to connect points in two locations where physical wiring is impossible. Examples include the space between a dock and a ship, or between a vehicle and a depot.
- • The 16 output points are relay outputs. Therefore, it is possible to connect loads directly to the outputs.
- • It uses the 2.4GHz frequency band and employs a Bluetooth wireless communication method that prevents frequency interference even when multiple sets are present in the same space.
- • The 16 input points are DC 24V inputs, with power separated internally using photocouplers.
- • The 16 output points are relay outputs. They operate by switching the contacts ON or OFF.
- • Two units form a set. They are paired (set to the same address) at the time of shipment.
- • When one input contact turns ON, the output contact on the status side turns ON. • Uses the 2.4GHz frequency band, ensuring no frequency interference even when multiple units are installed in the same space. (Time Division Synchronous Structure)
- • Dimensions (WxHxD): 145 x 115 x 38.5 mm
- • Transmission and reception are possible up to 100 meters in open areas free from interference.
- • Transmission and reception are impossible if there are metal barriers (doors, walls, machinery, etc.) between the unit and the device.
- • Since it uses the same frequency band as Wi-Fi, the transmission and reception range may be reduced if Wi-Fi is also being used in the same space.
