The E2S GNExCP7-PT in High-Visibility Yellow (Full Configuration Code: GNExCP7PTDPLBS3A1YNExxxRSxxxR / GNExCP7-PT Push Button MCP Series) is a high-reliability explosion-proof manual alarm and ESD station manufactured by E2S Warning Signals (UK) with 100% UK Origin. Molded from corrosion-proof, UV-stable Glass Reinforced Polyester (GRP) in an eye-catching yellow finish, this manual call point is specifically engineered for gas leak warning, process alarm signaling, and Emergency Shutdown (ESD) initiation across hazardous industrial environments (Zone 1, Zone 2, Zone 21, and Zone 22).

KEY PRODUCT FEATURES AND OPERATIONAL ADVANTAGES:
1. Ergonomic Push Button Mechanism with Protective Lift Flap:
Features a tactile push button actuator protected by an integral spring-loaded transparent lift flap. This configuration prevents accidental tripping while allowing rapid, decisive alarm triggering during plant emergencies without requiring glass replacement.
2. Robust Yellow GRP Corrosion-Free Housing:
Molded from high-grade flame-retardant, anti-static GRP in high-visibility Yellow (RAL 1003). Free of external metallic components prone to corrosion, it is completely immune to offshore salt spray, aggressive chemicals, and UV degradation with an IK09 impact resistance rating.
3. Universal Global Explosion-Proof & Marine Certifications:
Certified to rigorous international standards including ATEX, IECEx, and UKCA with ratings Ex db IIC T6 Gb and Ex tb IIIC T80°C Db, making it suitable for hazardous gas groups IIA, IIB, and IIC (including Hydrogen) as well as combustible dusts. Certified SIL 2 compliant in accordance with IEC 61508.
4. Integrated End-Of-Line & Series Monitoring Resistors (ExxxRSxxxR):
Pre-configured with built-in series and End-Of-Line (EOL) resistors, allowing fire & gas panels, DCS, and ESD controllers to continuously monitor line integrity, detect open/short-circuit faults, and verify activation status precisely.
5. IP66 / IP67 Ingress Protection:
Sealed with high-grade elastomeric gaskets to prevent ingress of fine dust, driving rain, and high-pressure washdown water jets, ensuring maximum internal switch contact protection.
6. Versatile Conduit Entries & Generous Wiring Space:
Equipped with dual M20 cable entries (with optional 1/2" NPT / 3/4" NPT adaptors) and a spacious internal terminal chamber for fast termination of heavy armored offshore cables.

TYPICAL INDUSTRIAL APPLICATIONS:
• Offshore Oil & Gas Platforms & FPSO Vessels: Manual Emergency Shutdown (ESD) stations and gas alarm points on processing decks.
• Oil Refineries & LNG/LPG Terminals: Triggering foam deluge systems, gas hazard alerts, and automated line shutoff valves.
• Chemical & Petrochemical Processing: Manual alert points for toxic chemical leaks, ammonia alerts, and solvent vapor release.
• Power Generation Plants & Gas Turbine Stations: Localized gas detection trip stations and manual process emergency stops.

• Manufacturer: E2S Warning Signals
• Product Line: Push Button Manual Call Point (GNExCP7-PT Series)
• Model / Order Code: GNExCP7PTDPLBS3A1YNExxxRSxxxR
• Country of Origin: United Kingdom - UK (100% UK Origin)
• Actuation Mechanism: Push Button with spring-loaded Protective Lift Flap
• Reset Function: Mechanical latching mechanism, resettable via dedicated reset tool (Tool Reset)
• Switch Contact Configuration: 1 x SPDT or 1 x DPDT
• Electrical Ratings:
  - Max. Operating Voltage: 250V AC / 50V DC
  - Max. Contact Current: 5A (AC) / 1A (DC)
• Resistor Configuration: Integrated Series and End-Of-Line (EOL) monitoring resistors (Code ExxxRSxxxR)
• Enclosure Material: Flame-retardant, anti-static Glass Reinforced Polyester (GRP)
• Housing Color: Yellow (RAL 1003) standard gas hazard / ESD shutdown finish
• Duty Inscription: Standard Gas Warning / Emergency Shutdown legend
• Cable Conduit Entries: 2 x M20 x 1.5 mm (Optional 1/2" NPT / 3/4" NPT)
• Terminal Block: Screw-clamp terminals (Wire capacity 0.5 mm² to 2.5 mm²)
• Explosion-Proof Ratings & Certifications:
  - ATEX: II 2G Ex db IIC T6 Gb (Ta -55°C to +70°C)
  - ATEX: II 2D Ex tb IIIC T80°C Db (Ta -55°C to +70°C)
  - IECEx: Ex db IIC T6 Gb, Ex tb IIIC T80°C Db
  - Hazardous Area Classification: Zone 1, Zone 2 (Gas) and Zone 21, Zone 22 (Dust)
  - Gas Groups: Group IIC, IIB, IIA / Temperature Class T6
  - Functional Safety: SIL 2 Compliant (IEC 61508)
  - Global Approvals: ATEX, IECEx, UKCA, DNV, MED, PESO, INMETRO, CCC
• Ingress Protection: IP66 / IP67 (Type 4X)
• Mechanical Impact Rating: IK09
• Ambient Operating Temperature: -55 °C ... +70 °C
• Storage Temperature: -55 °C ... +70 °C
• Relative Humidity: 0 ... 95% RH (Non-condensing)
• Enclosure Dimensions (W x H x D): Approx. 140 mm x 140 mm x 95 mm
• Net Weight: Approx. 1.3 kg
