The Guardian Line GLHD-SS Heavy Duty Stainless Steel Safety Rope Pull Switch (Part Number: 114105 - Model: GLHD-SS) manufactured by world-leading IDEM Safety Switches Ltd (United Kingdom) is engineered to provide emergency stop protection along long conveyor transport spans in demanding industrial environments, complying with ISO 13850 and IEC 60947-5-5 standards.

PRODUCT SPECIFICATIONS & FEATURES (PART NO: 114105):
- Part Number: 114105
- Product Model: GLHD-SS (Guardian Line Heavy Duty Stainless Steel)
- Dual Head Operating Mechanism: Incorporates bidirectional rope eyelets allowing safety cables to be tensioned from both directions. A single switch protects up to 250 meters of conveyor length (up to 125m on each side), significantly lowering hardware, installation, and wiring costs.
- Premium Construction: Cast in solid mirror-polished 316 Stainless Steel (Ra < 0.8 µm surface finish) designed specifically to resist harsh chemical environments, marine salt fog, and bacterial accumulation.
- Integrated Safety Elements:
  + Lid-mounted mushroom-head Emergency Stop (E-Stop) push button for immediate local trip isolation.
  + Multi-colour high-intensity LED beacon providing unmistakable visual status indication from long distances.
  + Built-in tension indicator window on the body for quick, accurate cable tension setup and routine inspection.

KEY ADVANTAGES:
- Positive break mechanism immediately interrupts safety circuits upon either a pull on the rope or accidental cable slack/breakage.
- IP67 and IP69K ingress protection withstands aggressive high-pressure detergent washdowns up to 80°C and 100 bar.
- Conforms to the highest machinery safety levels: Category 4, PLe (ISO 13849-1) and SIL 3 (IEC 62061).

• Manufacturer: IDEM Safety Switches Ltd
• Origin: United Kingdom
• Part Number: 114105
• Product Model: GLHD-SS (Dual Head Heavy Duty)
• Applicable Standards: ISO 13850, IEC 60947-5-5, IEC 60947-5-1, UL 508
• Safety Ratings: Category 4, PLe (ISO 13849-1), SIL 3 (IEC 62061)
• Protection Span: Up to 250 meters (up to 125 meters per side)
• Housing & Mechanism Material: Solid 316 Stainless Steel (Surface finish Ra < 0.8 µm)
• Contact Configuration: 4NC (Positive Break Safety Contacts) + 2NO (Auxiliary Signal Contacts)
• Contact Rating: AC-15 240V / 3A; DC-13 24V / 2.5A
• Emergency Stop Device: Integrated lid-mounted twist-to-reset mushroom E-Stop button
• Status Indication: Integrated dual-colour LED beacon
• Conduit Entries: 4 x M20 (or optional 1/2" NPT)
• Tensioning Pull Force: Compliant with ISO 13850 (< 125 N, deflection < 300 mm)
• Ingress Protection Rating: IP67 and IP69K (Dust-tight, submersible, and resilient to 80°C / 100 bar washdowns)
• Operating Temperature: -25°C to +80°C
• Mechanical Service Life: > 1,000,000 operating cycles
• Typical Applications: Seafood processing conveyors, confectionery and beverage bottling lines, pharmaceutical packaging, maritime bulk transfer terminals, chemical plants, and mineral processing.
