The KOFLOC PS-4-DC24 is a high-grade 4-channel dedicated industrial power supply unit developed and manufactured by KOFLOC (Kojima Instruments Inc., Japan). It is specifically engineered to power and support Mass Flow Controllers (MFC), Mass Flow Meters (MFM), and associated precision flow sensing instrumentation.

Utilizing an advanced switching regulator circuit, the KOFLOC PS-4-DC24 delivers a regulated DC 24V output with ultra-low ripple and noise, preventing measurement signal drift caused by electrical fluctuations in industrial grids. Featuring four dedicated output channels, it simultaneously supplies power to up to four MFC/MFM units with balanced voltage distribution. The unit incorporates comprehensive protection mechanisms including overcurrent, overvoltage, and auto-recovering short-circuit protection. Enclosed in a rugged metal housing with passive fanless heat dissipation and DIN-rail or panel mounting versatility, it offers reliable long-term performance for semiconductor cleanrooms, industrial gas mixing lines, and R&D testing setups.

• Manufacturer: KOFLOC (Kojima Instruments Inc.)
• Brand Origin: Japan
• Full Model Designation: PS-4-DC24
• Product Classification: 4-Channel Dedicated Power Supply Unit for Flow Instrumentation
• Rated Input Voltage: AC 100V – 240V (Universal input range: AC 85V – 264V, 50/60 Hz)
• Rated Output Voltage: DC 24V (Voltage regulation: ±1% or lower)
• Number of Output Channels: 4 dedicated independent channels
• Total Output Current Capacity: 2.5A – 3.0A (Total power rating approx. 60W – 75W)
• Per-Channel Current Rating: 0.6A – 1.0A / channel
• Output Ripple & Noise: Less than 50 mVp-p (Ultra-low electrical noise for sensor signal integrity)
• Power Conversion Efficiency: ≥ 85%
• Integrated Protection Functions:
  - Overcurrent Protection (OCP): Automatic current limiting with auto-recovery
  - Overvoltage Protection (OVP): Clamps/shuts down output above safety threshold
  - Short-Circuit Protection (SCP): Continuous hiccup mode with auto-recovery
• Status Indicators: Main AC power indicator LED and individual DC output channel status LEDs
• Termination Interface: Screw terminal blocks / dedicated multi-pin MFC connector interfaces
• Operating Ambient Temperature: 0°C to 50°C
• Operating Ambient Humidity: 20% to 85% RH (Non-condensing)
• Mounting Configuration: 35mm DIN-rail mounting or direct panel screw fixing
• Enclosure Construction: Powder-coated steel casing, fanless natural convection cooling
• Compatible Equipment: KOFLOC Mass Flow Controllers (3660, 3760, 3810, 8500 series etc.), Mass Flow Meters, pressure transmitters, and precision pneumatic automation modules
